SPM for BricsCAD > Features > Terrain wizard > 2D or 3D Contours

2D or 3D Contours in BricsCAD

Create minor and major Contours, label Contour altitudes, separate in different Layers and different color models. Optional attached Data Tables will include Contour elevation values and types

Editions: Professional

2D or 3D Contours

Spatial Manager™ for BricsCAD allows you to generate both minor and major contour lines in 2D or 3D formats.

Contour altitudes can be labeled automatically, and contours can be organized into separate layers with distinct color schemes for clear visualization.

Additionally, optional attached data tables can store contour elevation values.

Related features
3D Points<span style='font-size: 1rem;'> - <a href='../3d-points/' class='app_color_link'>More info ></a></span>

3D Points

Use Points or Blocks selected in the drawing or built from Elevation service providers in any selected area. You can also use already generated terrain as source 3D geometry

Use BricsCAD Civil Points<span style='font-size: 1rem;'> - <a href='../use-bricscad-civil-points/' class='app_color_link'>More info ></a></span>

Use BricsCAD Civil Points

Create surfaces from BricsCAD Civil Points easily with Spatial Manager, optimizing project workflows

3D Terrains<span style='font-size: 1rem;'> - <a href='../3d-terrains/' class='app_color_link'>More info ></a></span>

3D Terrains

3D models generation using 3D Meshes or other CAD/BIM objects from the selected 3D objects

Automatic image projection and fitting of any Background Map (preset or user-configured) on one or more Terrains in their actual location

Related Posts
Add elevation data to existing points in DWG/DXF

Spatial Manager have some utilities for working with terrains and elevations, one of them allows to search elevations for existing points. Doing some steps it is possible to create a... more

Extract 3D points from other objects

Spatial Manager (CAD versions) includes the option to Insert Nodes when importing objects such as Polylines or Polygons. These nodes can be created as Points or as Block Inserts (if... more

Contours and imported objects Label Masks

In order to enhance the visibility of Contour Labels, ‘Spatial Manager’ (CAD versions) now includes some new options which can also be applied to the object Labels while Importing. In... more

Contours: 2D, 3D, Labels, and more options...

Spatial Manager Terrain Assistant, available in the CAD versions (AutoCAD, BricsCAD and ZWCAD), provides the user with intuitive tools for processing 2D/3D Terrain information (Points, Contours, and Digital Terrain Models).... more
